ISO9001 certified good quality waterproof water tank insulation

Product Description

ISO9001 certified good quality waterproof water tank insulation



  Product Show
SST

Product Parameters   SST



Capacity L 100 200 300 400 500 600 800 1000
Inner tank diameter mm  Φ370  Φ470  Φ500  Φ550  Φ600  Φ650  Φ700  Φ800
Out shell diameter mm  Φ470  Φ560  Φ600  Φ650  Φ700  Φ760  Φ800  Φ900
Inner tank material mm         SUS304 / SUS316L / Duplex2205 / Duplex2304
Out shell material mm         galvanized steel with painting / stainless stell / PU
Out shell color           white / silver-grey / blue /red / golden / stainless stell
Max.working pressure bar  6  6  6  6  6  6  6  6
Max.testing pressure bar 10  10  10  10  10  10 10  10
Max.running temperature  90  90  90 90  90  90  90  90
Heating loss W/K  0.65  0.72  0.89  1.02  1.15  1.26  ——  ——
Standing loss W  30  33  40  46 52 57  ——  ——
ERP Class    A  A  A  A  A  A  A  A
Electrical heater kw  1.5  1.5  1.5  1.5  3  3  3 3
Mg.Anode mm         Φ22*300
Water connection       G / BSP / NPT 3/4"     G / BSP / NPT 1"
Packing size mm

L:540

W;540

H:117

L:630

W:630

H:1440

L:670

W:670

H:163

L:720

W:720

 H:1920

L:780

W:780

 H:1930

L:850

W:850

  H:1940

 Φ900*2200  Φ980*2420



Unique Technology/advantage SST

















Contact us if you need more details on Waterproof Water Tank Insulation. We are ready to answer your questions on packaging, logistics, certification or any other aspects about Waterproof Water Tank Insulation、Waterproof Water Tank Insulation. If these products fail to match your need, please contact us and we would like to provide relevant information.

Product Categories : Multifunction Tank
