SST back-up water heater for heat pump water heater ,backup heater
Product Description
SST back-up water heater for heat pump water heater ,Backup Heater




Capacity | L | 100 | 200 | 300 | 400 | 500 | 600 | 800 | 1000 |
Inner tank diameter | mm | Φ370 | Φ470 | Φ500 | Φ550 | Φ600 | Φ650 | Φ700 | Φ800 |
Out shell diameter | mm | Φ470 | Φ560 | Φ600 | Φ650 | Φ700 | Φ760 | Φ800 | Φ900 |
Inner tank material | mm | SUS304 / SUS316L / Duplex2205 / Duplex2304 | |||||||
Out shell material | mm | galvanized steel with painting / stainless stell / PU | |||||||
Out shell color | white / silver-grey / blue /red / golden / stainless stell | ||||||||
Max.working pressure | bar | 6 | 6 | 6 | 6 | 6 | 6 | 6 | 6 |
Max.testing pressure | bar | 10 | 10 | 10 | 10 | 10 | 10 | 10 | 10 |
Max.running temperature | ℃ | 90 | 90 | 90 | 90 | 90 | 90 | 90 | 90 |
Heating loss | W/K | 0.65 | 0.72 | 0.89 | 1.02 | 1.15 | 1.26 | —— | —— |
Standing loss | W | 30 | 33 | 40 | 46 | 52 | 57 | —— | —— |
ERP Class | A | A | A | A | A | A | A | A | |
Electrical heater | kw | 1.5 | 1.5 | 1.5 | 1.5 | 3 | 3 | 3 | 3 |
Mg.Anode | mm | Φ22*300 | |||||||
Water connection | G / BSP / NPT 3/4" | G / BSP / NPT 1" | |||||||
Packing size | mm | L:540 W;540 H:117 | L:630 W:630 H:1440 | L:670 W:670 H:163 | L:720 W:720 H:1920 | L:780 W:780 H:1930 | L:850 W:850 H:1940 | Φ900*2200 | Φ980*2420 |

Q1. Material?
For inner tank we have SUS304,SUS316L and Duplex 2205. The most popular is Duplex 2205. For the outer shell is galvanize with painting and stainless steel both are available.Also for the big tank we can do the PU coat.
Q2.Volume?
For now we can do from 20L to 1000L.
Q3. Lead time?
For the LCL order is 15 days after received the payment . for the container order is 25 days after received the advance payment.
BACK HOME
Contact us if you need more details on Backup Heater. We are ready to answer your questions on packaging, logistics, certification or any other aspects about Back-up Water Heater、Heat Pump Water Heater. If these products fail to match your need, please contact us and we would like to provide relevant information.
Product Categories : Backup Heater
